QSE 6 + 10

Hybrid air heater all-electric, 16 kW

  • Quick heating by booster
  • Sustainable heating solution
  • Can be combined with solar panels
  • Heats and cools
  • No CO2 emissions
QSE 6 + 10

Hybrid air heater all-electric, 16 kW

  • Quick heating by booster
  • Sustainable heating solution
  • Can be combined with solar panels
  • Heats and cools
  • No CO2 emissions

Description

The hybrid air heater QSE 6+10 consists of a heat pump of 6 kW and an inside unit with water coil, an axial fan and a electrical booster of 10 kW. Still the inside unit fits fine in smaller areas like in shops, showrooms, cafeterias, etc. The water coil with modulating EC fan are the heat release system for the heat pump while the booster is actived when the heat pump does not supply enough heat to reach the programmed room temperature.
At the front of the heater a discharge grill with adjustable louvres takes care of an even air distribution in the room. Preferably, complemented with destratification fans.
During the summer the QSE also provides cooling to some extent.

Efficient energy management

The Smart Controller controls both the heat pump and the indoor unit based on the measured room temperature and determines when the booster should jump in. By choosing, this can be done partly on the basis of the user's programmed electricity rates.  The QSE can also be connected to a building management system, so that the performance of the system can be monitored even better.

Features

  • all-electric
  • heating capacity 16 kW (6kW heat pump + 10kW booster)
  • cooling (at water temperature min. >15°C)
  • efficient and silent EC fan motor
  • 0% NOx emission
  • suspension on wall brackets or threaded bar
  • simple installation

Technical features

Total heating capacity 15.9kW
Heating capacity electrical heating 9.9kW
Heat emission heat pump heat exchanger at 20 °C 35/30 according to EN 1397 6kW
Cooling capacity heat pump heat exchanger at 27 °C 12/17 according to EN 1397 6.5kW
Air volume 324m³/h - 1800m³/h
Max. throw horizontal 15m
Supporting protocol for Modbus Yes
Connection voltage 400V - 400V
Nominal current 15.9A
Supplementary electricity consumption in standby-mode (Psb) 5
Nominal diameter connections heat pump 3/4 inch (20)
Min. mounting height (horizontal air distribution) 2.7m
Sound pressure level at height of 5 metres 35dB(A) - 54dB(A)
Water content 2l
Weight including filling 47kg

Images

Accessories

Controls
HPX 06
Suspension
  • GA8610
    Console Set (wall- or ceiling suspension) (S)
    Article number GA8610
    More information
Other

Service parts

View our service parts for the QSE 6 + 10 (and earlier models) in the parts shop.

Parts shop

The Qwikshift QSE is an all-electric hybrid heater which combines a heat pump with an innovative booster and smart control.
